EYC Thermal Mass Flow Transmitter FTM06D

Output：4 ... 20 mA+RS-485 / 0... 10 V+RS-485 / Impulse+RS-48

Input：Thermal mass flow sensor

Measuring range：Air：0 ... 120 m/s

Accuracy：±1.5% F.S.

IP rating：IP65

Thermal mass flow sensor

Can measure air velocity and air volume

Analog / RS-485 / Impulse output

Built-in temperature compensation, accurate measurement

Using constant temperature anemometer(CTA) technology, good sensitivity

Unit setting：[m/s], [ft/s], [Nm3/h], [L/min], [°C], [°F]

Strong stainless steel housing, for a variety of harsh environments

Semiconductor / Electronics / Papermaking / Food / Pharmaceuticals / Biotechnology industry / Plant CDA system / Refrigerated dryer adsorption / PSA nitrogen(N2) generator
